BIRO Model 44SSFH (Stainless Steel/Fixed Head) Power Meat Saw
3HP Bandsaw Fixed Head
You are here:
Product Overview
The BIRO Model 44SSFH (Stainless Steel/Fixed Head) Power Meat Saw equipped with a 142” (3606.8 mm) Saw Blade is a heavy-duty, high-volume bandsaw that is well-suited for continuous intensive operation. The 3HP industrial motor, at 4000 feet per minute as standard blade speed, provides you with plenty of power and efficiency. BIRO’s unique EZ-Flow meat carriage with 8 Stainless Steel Bearings helps reduce operator fatigue and increase productivity. The watertight magnetic electrical controller helps ensure safe, reliable operation. The 18” (457mm) diameter saw blade wheels with a 17-5/32” (435.8mm) horizontal cutting clearance and a full 17-1/8” (435mm) vertical cutting clearance lets you cut larger product pieces than other saws. A broad range of designs, configurations, and options give you the flexibility to own a saw that fits your exact needs. The BIRO Model 44SSFH Series Power Meat Saws have superior durability and engineering features you’ve come to expect from BIRO, which means you’ll get years of reliable use, low maintenance, and minimal overall cost of ownership.
Product Description
Construction: Stainless steel.
Cleaning Unit: Stainless steel body, long life carbide guide insert, stainless steel saw cleaners, removable as a unit for easy cleaning (assembly also adjustable as a unit).
Drive System: Non slip silent v-belt, tension adjustable.
Legs: Four stainless steel leg bolt levelers.
Meat Carriage: Stainless steel EZ-flow movement with eight stainless steel bearings.
Meat Gauge Plate: Stainless steel faced, adjustable from 1/16” (1.59 mm) to 6-1/2” (165 mm) locks in position, can be disengaged, entire assembly removable for cleaning.
Motor Compartment: Sealed off from meat contact areas, easily accessible through removable panel door.
Rear Platter: Stainless steel, held in place with two push pull hold down stainless steel rods (where applicable).
Safety End Cut Pusher Plate: Standard, removable pusher plate, storage hanger provided.
Certification: U.S.D.A., U.L., N.S.F., C.F.I.A. (C.S.A., STD., DP, 3HP-230-60-3)
Weight Standard Configuration:
Uncrated: 600 lbs. (272 kg.) approximate.
Crated: 700 lbs (318 kg.) approximate.
Dims. Standard Configuration Crated:L = 54”(137 cm), W = 45”(114 cm), H = 83”(211 cm).
Standard Features: Two saw blades, operation and parts manual, safety wall poster, end cut safety pusher plate (where applicable).
Switch: Watertight magnetic with thermal overload and under voltage protection.
Head and Door: Stainless steel fixed head, removable head door.
Blade Standard: Hard tooth, three teeth per inch (8.5 mm between teeth), 142” (3606.8 mm) long x 5/8” (16 mm) wide, .022” (.56 mm) thick (two supplied with each saw).
Blade Speed: Std. 4000 feet (1219 m) per minute approx. Higher blade speed available depending on product to be cut.
Blade Back-up Guides: Upper and lower blade backup guides, (both with long life carbide back-up inserts). Both assemblies removable for easy cleaning.
Blade Wheels: 18” (457 mm) cast iron, chrome nickel plating, upper wheel assembly lifts out.
Bearings: Heavy duty tapered roller bearings used in upper wheel and lower bearing housings.
Catch Pan: Poly, extra deep (rounded corners) pan sealed off from other parts of base, accessible through base hinged door.
Options
Stainless Steel Wheels
